Powerful New Desktop Document Scanner

An affordable, easy to use desktop scanner and is the ideal solution for a variety of business scanning needs for SMBs and SOHOs. The new ADS-2200 offers a 50-sheet Automatic Document Feeder (ADF) to handle a business most diverse and high-volume scan jobs whilst still being compact enough for small workspaces, front of house counters and office desktops where space is often limited. Whether its a double-sided contract, small receipt, an embossed ID card of up to 1.32mm thickness, or a 5000mm long paper, Brothers ADS-2200 has the capability to be loaded with mixed sizes and weights, proving to be a compact yet powerful machine.

GENERAL SPECIFICATION

Memory Capacity	Standard	512 MB
Power Source	AC: 220 - 240 V, 50/60 Hz
Touchscreen LCD (Liquid Crystal Display)*1 (ADS-2700W)	Touchscreen 71.1 mm TFT Colour LCD
Approx. Power Consumption*2	Scanning*3	ADS-2200:21 W ADS-2700W:23 W
Ready*4	ADS-2200:4.7 W ADS-2700W:6.6 W
Sleep	ADS-2200:0.8 W ADS-2700W:1.0 W
Power Down	ADS-2200:0.1 W ADS-2700W:0.1 W
Dimensions
Approx. Weights	ADS-2200:2.5 kg ADS-2700W:2.7 kg
Temperature	Operating	5 C to 35 C
Storage	0 C to 40 C
Humidity	Operating	20% to 80%
Storage	10% to 90%
ADF (automatic document feeder)	Up to 50 pages (Paper: 80 g/??Legal size, or less than 5 mm)

*1Measured diagonally

*2Measured when the machine is connected to your computer.

*3When using 2-sided (duplex) scanning.

*4When the USB port is connected.

Document Specifications

Paper Type	Plain Paper, Thin Paper, Thick Paper, Thicker Paper, Recycled Paper, Business Card, Plastic Card
Document Size	Width	51 to 215.9 mm
Length	51 mm to 355.6 mm

Scanner Specifications

Colour/Monochrome	Yes/Yes
TWAIN Compliant	Windows	WindowsXP Home (SP3) / WindowsXP Professional (only 32bit SP3) / Windows7 (SP1) / Windows8 / Windows8.1 / Windows10 Windows Server2008 R2 / Windows Server2012 / Windows Server2012 R2 / Windows Server2016
Mac	macOS v10.10.5 / 10.11.x /10.12.x*1
WIA Compliant	Windows	Windows7 (SP1) / Windows8 / Windows8.1 / Windows10
ICA Compliant	Mac	macOS v10.10.x / 10.11.x /10.12.x*1
Colour Depth	Input	48 bit color processing
Output	24 bit colour Processing
Resolution	Interpolated	Up to 1200 x 1200 dpi
Optical	Up to 600 x 600 dpi
Scanning Width	Up to 215.9 mm
Greyscale	256 levels
Max. Speed	For detailed specifications visit

*1For the latest driver updates for the version of OS X you are using, visit

Direct Scan Feature (Scan to USB) Specifications

Compatible Media	USB flash drive 1*1
Interface	Interface USB 2.0 Hi Speed

*1USB Mass Storage standard up to 64 GB

Supported formats: FAT12/FAT16/FAT32/exFAT

Interface Specifications

USB	Hi-Speed USB 2.0*1 Use a USB 2.0 interface cable (Type A/B) that is no more than2.0 metreslong.
LAN (ADS-2700W)	Use an Ethernet UTP cable category 5 or later.
Wireless LAN (ADS-2700W)	IEEE 802.11b/g/n (Infrastructure Mode) IEEE 802.11g (Wi-Fi Direct)

Your machine has a Hi-Speed USB 2.0 interface. The machine can also be connected to a computer that has a USB 1.0/1.1 interface.

Third-party USB ports are not supported.
